Midea V6 Series

V6 VRF 50Hz
20
Midea V6 Series Service Manual
30/32HP
Figure 2-2.5: 30/32HP piping diagram
Legend
No.
Parts name
No.
Parts name
1
Compressor
16
Heat exchanger cooling electric control box
2
Discharge temperature switch
T3
Heat exchanger temperature sensor
3
High pressure switch
T4
Outdoor ambient temperature sensor
4
High pressure sensor
T6A
Plate heat exchanger inlet temperature sensor
5
Oil separator
T6B
Plate heat exchanger outlet temperature sensor
6
Four-way valve
T7C1
Compressor A discharge temperature sensor
7
Heat exchanger
T7C2
Compressor B discharge temperature sensor
8
Electronic expansion valve (EXV)
SV4
Oil return valve
9
Low pressure switch
SV5
Fast defrosting (in heating) and unloading (in cooling) valve
10
Fan motor
SV6
Refrigerant bypass EXV valve
11
Fan
SV7
Refrigerant bypass indoor units valve
12
Stop valve (liquid side)
SV8A
Compressor A vapor injection valve
13
Stop valve (gas side)
SV8B
Compressor B vapor injection valve
14
Plate heat exchanger
SV9
Compressor B pressure balance valve
15
Accumulator
7
1
1
15
15
12
9
3
4
5
6
11
10
11
10
14
8
8
8
13
EXVB
EXVA
EXVC
E
S
C
SV6
T3
T4
T6B
T6A
SV5
SV9
S
V7
S
V4
SV8A
SV8B
T7C1
T7C2
2
2
16
