Midea V6 Series Service Manual
 All EXVCs are fully closed.
 When some outdoor units are running and some outdoor units are in standby:
 EXVCs on running outdoor units are controlled according to temperature different between plate heat exchanger
inlet and outlet. EXVCs of units in standby are fully closed.
 When all outdoor units are running:
 All EXVCs are controlled according to temperature different between plate heat exchanger inlet and outlet.
5.6 Outdoor Fan Control
The speed of the outdoor unit fans is adjusted in steps, as shown in Table 3-5.3.
Table 3-5.3: Outdoor fan speed steps
Fan speed index
Fan speed (rpm)
8-16HP
18-22HP
24-32HP
FANA / FANB
FANA / FANB
0
0
0 / 0
0 / 0
1
120
150 / 0
120 / 0
2
150
190 / 0
150 / 0
3
170
230 / 0
170 / 0
4
190
270 / 0
190 / 0
5
210
310 / 0 (150 / 150)
210 / 0
6
230
350 / 0 (180 / 180)
230 / 0
7
250
380 / 0 (210 / 210)
250 / 0 (120 / 120)
8
270
410 / 0 (240 / 240)
270 / 0 ( 150 / 150)
9
290
280 / 280
330 / 0 (170 / 170)
10
310
320 / 320
370 / 0 (190 / 190)
11
330
360 / 360
210 / 210
12
350
400 / 400
230 / 230
13
370
440 / 440
250 / 250
14
390
480 / 480
270 / 270
15
410
520 / 520
290 / 290
16
430
560 / 560
310 / 310
17
450
600 / 600
330 / 330
18
470
640 / 640
350 / 350
19
490
680 / 680
370 / 370
20
510
720 / 720
400 / 400
21
530
760 / 760
430 / 430
22
560
800 / 800
470 / 470
23
580
840 / 840
510 / 510
24
600
880 / 880
550 / 550
25
630
910 / 910
600 / 600
26
650
940 / 940
650 / 650
27
700
980 / 980
700 / 700
28
750
1010 / 1010
750 / 750
29
800
1020 / 1020
800 / 800
30
850
1050 / 1050
830 / 830
31
880
1080 / 1080
850 / 850
32
920
1120 / 1120
870 / 870
33
920
1140 / 1140
890 / 890
34
920
1140 / 1140
920 / 920
35
920
1140 / 1140
920 / 920
36 (ESP 40Pa mode)
950
1200 / 1200
950 / 950
37 (ESP 60Pa mode)
980
1200 / 1200
980 / 980
Note:
1. For 18-22HP unit fan speed 5 to 8 and 24-32HP unit fan speed 7 to 10, when fan speed decreases, the fan speed is shown in the bracket; when fan speed
increases, the fan speed is shown without bracket.
