Midea V6 Series Service Manual
1 Outdoor Unit Electric Control Box Layout
8-16HP
Figure 5-1.1: 8-16HP top layer of electric control box
Figure 5-1.2: 8-16HP bottom layer of electric control box
Power supply
terminals
Communication
terminals block
Inductor
Filter boardMain PCB
Inverter
module Reactor
Pipe temp. sensor
Compressor connection wire
Fan module
Bridge rectifier
