Midland ALAN 48 EXCEL MULTI Owner's Manual

POLISH
1
SPIS TRESCI
Wprowadzenie ........................................................................................
Funkcje i elementy sterowania ...............................................................
Instalacja ................................................................................................
Zasilanie ...............................................................................................
Instalowanie anteny .............................................................................
Uzywanie ALANA 48 EXCEL MULTI .......................................................
Wybieranie zakresu czestotliwosci ......................................................
Tabela czestotliwosci ...........................................................................
Dane techniczne .....................................................................................

Midland ALAN 48 EXCEL MULTI Specifications

Operating Environment

operating temperature range	-10°/+55° C
frequency range	26.565 - 27.99125 MHz
frequency control	PLL

Power

dc input voltage	13.2/24 Vdc ±15%
current drain at standby (13.2V)	450mA
current drain at standby (24V)	520mA

Receiver Specifications

receiving system	Dual conversion superheterodyne
intermediate frequency	I°IF:10.695 MHz II°IF:455 KHz
sensitivity	0.5µV for 20dB SINAD in AM/FM

Transmitter Specifications

output power	duty cycle 10% 4W AM/FM @ 13.2 Vdc
modulation	FM:1.8KHz ± 0.2khz AM: 85% to 95%
frequency response	400 Hz ÷ 3 KHz

Weight and Dimensions

size	150(L) x 45(H) x 175(D)mm
weight	1Kg
