Midland ALAN 48 EXCEL MULTI Owner's Manual

POLISH
9
DANE TECHNICZNE
Podstawowe
Kanaly .......................................................................................... 40 FM (Patrz tabela)
Zakres czestotliwosci .....................................................................25.615-30.105 MHz
Kontrola czestotliwosci ............................................................................................PLL
Zakres temp. pracy ...................................................................................... -10°/+55° C
Zasilanie ........................................................................................... 13.2/24 Vdc ±15%
Wymiary .............................................................................. 150(L) x 45(H) x 175(D)mm
Waga .........................................................................................................................1Kg
ODBIORNIK
system odbioru ........................................superheterodyna z podwojna przemiana cz.
czestotliwosci posrednie ...............................................I°IF:10.695 MHz II°IF:455 KHz
Czulosc ......................................................................0.5µV for 20dB SINAD in AM/FM
Moc wyjsc. audio @10% THD ..............................................................2.0 W @ 8 Ohm
Znieksztalcenia audio ................................................................. Less than 8% @ 1KHz
Tlumienie cz. lustrzanej ......................................................................................... 65dB
Separacja kanalow ................................................................................................. 65dB
Odstep sygnal/szum .............................................................................................. 45dB
Pobor pradu podczas czuwania .............................................................. 13.2V: 450mA
..................................................................................................................... 24V: 520mA
NADAJNIK
Moc wyjsciowa ............................................... duty cycle 10% 4W AM/FM @ 13.2 Vdc
Modulacja ...................................................................................... FM:1.8KHz ± 0.2khz
.............................................................................................................AM: 85% to 95%
Pasmo przenoszenia .............................................................................400 Hz ÷ 3 KHz
Impedancja wejsciowa ............................................................ RF 50 Ohm unbalanced
Odstep sygnal/szum ......................................................................................40 dB MIN
Pobor pradu .................................................................13.2V: 1300 mA (bez modulacji)
..........................................................................................24V: 1600mA (bez modulacji)
Producent zastrzega mozliwosc zmian.

Midland ALAN 48 EXCEL MULTI Specifications

Operating Environment

operating temperature range	-10°/+55° C
frequency range	26.565 - 27.99125 MHz
frequency control	PLL

Power

dc input voltage	13.2/24 Vdc ±15%
current drain at standby (13.2V)	450mA
current drain at standby (24V)	520mA

Receiver Specifications

receiving system	Dual conversion superheterodyne
intermediate frequency	I°IF:10.695 MHz II°IF:455 KHz
sensitivity	0.5µV for 20dB SINAD in AM/FM

Transmitter Specifications

output power	duty cycle 10% 4W AM/FM @ 13.2 Vdc
modulation	FM:1.8KHz ± 0.2khz AM: 85% to 95%
frequency response	400 Hz ÷ 3 KHz

Weight and Dimensions

size	150(L) x 45(H) x 175(D)mm
weight	1Kg
