Problem Symptom Probable Cause Check Solution
Foot function not
operating properly.
No Foot Up. Treatment pan not in the stowed position. If treatment pan is not completely pushed in. Push treatment pan all the way in.
Active Sensing Technology
TM
activated. For obstruction under the foot section. Remove object from under the foot section.
System malfunction. Error code on Machine Control PC Board. Refer to: Error Codes
Malfunctioning Wired Controls. Wired Controls. Refer to: Wired Controls Malfunctioning
Malfunctioning Wireless Controls. Wireless Controls. Refer to: Wireless Controls Malfunctioning
Treatment Pan switch. Wire connections at J6 on Machine Control
PC Board and at switch.
Secure wire connections.
Refer to: Fuses and Connections
Test switch.
Refer to: Smart Sensor Switches
Replace Switch.
Foot Smart Sensor switches. Wire connections at J18 on Machine Control
PC Board and at switches.
Secure wire connections.
Refer to: Fuses and Connections
Check Green and White wire connections
at four pin inline connection next to
Motor Control Hub PC Board.
Secure wire connections.
Test switches.
Refer to: Smart Sensor Switches
Replace switch.
Foot Up limit switch. Wire connections at J4 on Motor Control Hub
PC Board and at limit switch.
Secure wire connections.
Refer to: Fuses and Connections
Test limit switch.
Refer to: Foot Actuator / Limit Switches
Replace limit switch.
Foot Up Overtravel limit switch. Wire connections at J4 on Motor Control Hub
PC Board and at limit switch.
Secure wire connections.
Refer to: Fuses and Connections
Test limit switch.
Refer to: Foot Actuator / Limit Switches
Replace limit switch.
