Midmark 630 - Error Code; Error Definition

English-16
004-1055-00
TP210 Rev. A
© 2013 Midmark Corp. | 60 Vista Drive Versailles, OH 45380 USA | 1-800-643-6275 | 1-937-526-3662 |
[Revised: mo/dd/yr]
ID Code 01 (Machine Control Board)
Error Code Error Denition Probable Cause Correction
00
Power-Up Image Fault Board Malfunction.
Disconnect power cord for at least ve seconds, then plug back in.
Replace Machine Control PC Board.
01
Power-Up Memory Fault Board Malfunction.
Disconnect power cord for at least ve seconds, then plug back in.
Replace Machine Control PC Board.
02
Power-Up Clock Fault Board Malfunction.
Disconnect power cord for at least ve seconds, then plug back in.
Replace Machine Control PC Board.
03
Power-Up Clock Fault Board Malfunction.
Disconnect power cord for at least ve seconds, then plug back in.
Replace Machine Control PC Board.
04
Power-Up Voltage Fault
Loose connection.
Check all connections between Machine Control Board and
Power Supply PC Board.
Board Malfunction.
Disconnect power cord for at least ve seconds, then plug back in.
Replace Machine Control PC Board.
05
Process Execution Fault Board Malfunction.
Disconnect power cord for at least ve seconds, then plug back in.
Replace Machine Control PC Board.
06
Power-Up Initialization Fault Board Malfunction.
Disconnect power cord for at least ve seconds, then plug back in.
Replace Machine Control PC Board.
07
Headrest Clearance
Position of table.
Refer to: Active Sensing Technology
TM
Activate Back Up, Base Up, and/or Tilt Down.
08
Back Cover Clearance
Position of table.
Refer to: Active Sensing Technology
TM
Activate Back Up, Base Up, and/or Tilt Down.
09
Foot Clearance
Position of table.
Refer to: Active Sensing Technology
TM
Activate Base Up, Tilt Up, and/or Foot Up.
0A
Programmability Time-out
The Program button was pressed and no buttons
were pressed within the allotted time.
Error goes away by itself.
0b
Programmability Mistake
The Program button was pressed to initiate
programming a position and a non-programmable
button was attempting to be programed.
Error goes away by itself.
0C
Programmability Error
The program command was received, and during
the program time a proper command was received;
however, at least one of the axis positions was out of range.
Error goes away by itself.
Run all functions to their maximum and minimum positions.
Calibrate Table. Refer to: Calibration Procedure
0d
Calibration Failed Table not calibrated. Reference associated error code(s). Calibrate Table. Refer to: Calibration Procedure
0E
Calibration Not Completed
Table not calibrated.
Movement button on Hand / Foot Control pressed.
Calibrate Table. Refer to: Calibration Procedure
0F
Calibration Foot Extension Error Foot extension is extended. Move foot extension in.
