ID Code 03 (Back / Motor Control Hub Board) - continued
Error Code Error Denition Probable Cause Correction
0A
Overtravel Error
Loose wire connection.
Check and secure wire connections at J12 on Motor Control Hub PC Board and
at Overtravel limit switch(es). Refer to: Fuses and Connections
Disconnect power cord for at least ve seconds, then plug back in.
Overtravel limit switch(es).
Test / Replace switch. Refer to: Back Actuator / Limit Switches
Disconnect power cord for at least ve seconds, then plug back in.
0b
Hall Sensors
Loose wire connection.
Check and secure hall sensor wire connection at J10 on Motor Control Hub PC Board.
Refer to: Fuses and Connections
Motor Failure. Replace Back actuator motor.
0C
Motor Current Excessive load on actuator.
Check / Reduce patient load. (650 lb. Maximum)
Check mechanical structure for binding.
0d
Motor Run On Error
The motor has been detected moving for a longer period of
time than the run-on time allows.
Check actuator / motor and limit switches.
0E
Motor Stall Error
Excessive load on actuator.
Check / Reduce patient load. (650 lb. Maximum)
Check mechanical structure for binding.
Loose wire connection.
Check and secure wire connections at J11 on Motor Control Hub PC Board.
Refer to: Fuses and Connections
0F
Motor Direction Error
The motor is being commanded to move in one direction,
but is actually moving in another.
Check actuator / motor.
