ID Code 04 (Tilt / Motor Control Hub Board)
Error Code Error Denition Probable Cause Correction
00
Power-Up Fault Board malfunction.
Disconnect power cord for at least ve seconds, then plug back in.
Replace Motor Control Hub PC Board.
01
Power-Up Initialization Fault Board malfunction.
Disconnect power cord for at least ve seconds, then plug back in.
Replace Motor Control Hub PC Board.
02
Calibration Failed / Not Complete
The maximum position was unable to be set.
Calibrate Table. Refer to: Calibration Procedure
A motor control error occurred.
03
Low Voltage 48 VDC
Loose connection.
Check all connections between Power Supply PC Board and Motor Control Hub PC Board,
and all connections between Machine Control PC Board and Motor Control Hub PC Board.
Motor Control Hub PC Board fuse blown. Test / Replace F2 fuse on Motor Control Hub PC Board.
Power Supply PC Board fuse(s) blown. Test / Replace F3 & F4 fuses on Power Supply PC Board.
Board Malfunction.
Disconnect power cord for at least ve seconds, then plug back in.
If LED’s (D-21 & D-22) are illuminated on Power Supply PC Board, check for 24 VDC at
J-13 on Motor Control Hub Board. If voltage is present, replace Motor Control Hub
PC Board. If LED’s (D-21 & D-22) are not illuminated, test Power Toroid
04
Low Voltage 48 VDC
Loose connection.
Check all connections between Power Supply PC Board and Motor Control Hub PC Board,
and all connections between Machine Control PC Board and Motor Control Hub PC Board.
Motor Control Hub PC Board fuse blown. Test / Replace F2 fuse on Motor Control Hub PC Board.
Power Supply PC Board fuse(s) blown. Test / Replace F3 & F4 fuses on Power Supply PC Board.
Board Malfunction.
Disconnect power cord for at least ve seconds, then plug back in.
If LED’s (D-21 & D-22) are illuminated on Power Supply PC Board, check for 24 VDC at
J-13 on Motor Control Hub Board. If voltage is present, replace Motor Control Hub
PC Board. If LED’s (D-21 & D-22) are not illuminated, test Power Toroid
05
Low Voltage 5 VDC
Loose connection.
Check all connections between Power Supply PC Board and Motor Control Hub PC Board,
and all connections between Machine Control PC Board and Motor Control Hub PC Board.
Board Malfunction.
Disconnect power cord for at least ve seconds, then plug back in.
Replace Motor Control Hub PC Board.
