ID Code 05 (Foot / Motor Control Hub Board) - continued
Error Code Error Denition Probable Cause Correction
10
Communication Error to
Machine Control
Message / Communication failure.
Error goes away by itself.
Disconnect power cord for at least ve seconds, then plug back in.
11
Corrupt Memory Last save to memory failed.
Disconnect power cord for at least ve seconds, then plug back in.
Replace Motor Control Hub PC Board.
12
Memory Save Error Saving to memory failed.
Disconnect power cord for at least ve seconds, then plug back in.
Replace Motor Control Hub PC Board.
13
Memory Recall Error Recalling information from memory failed.
Disconnect power cord for at least ve seconds, then plug back in.
Replace Motor Control Hub PC Board.
14
Memory Erase Error Erasing information from memory failed.
Disconnect power cord for at least ve seconds, then plug back in.
Replace Motor Control Hub PC Board.
15
I2C Slave Not Present
Loose wire connection.
Check and secure wire connections at J3 on Power Supply PC Board
and J13 on Motor Control Hub PC Board. Refer to: Fuses and Connections
Check and secure wire connections at J16 on Machine Control PC Board
and J14 on Motor Control Hub PC Board. Refer to: Fuses and Connections
Power Supply PC Board fuse(s) blown. Test / Replace F3 & F4 fuses on Power Supply PC Board.
Motor Control Hub PC Board.
Check supply power to Motor Control Hub PC Board.
Refer to: Motor Control Hub PC Board Supply Power
Power Supply PC Board.
Check supply power to Motor Control Hub PC Board.
Refer to: Motor Control Hub PC Board Supply Power
16
I2C Slave Not Initialized
Loose wire connection.
Check and secure wire connections at J3 on Power Supply PC Board
and J13 on Motor Control Hub PC Board. Refer to: Fuses and Connections
Check and secure wire connections at J16 on Machine Control PC Board
and J14 on Motor Control Hub PC Board. Refer to: Fuses and Connections
Power Supply PC Board fuse(s) blown. Test / Replace F3 & F4 fuses on Power Supply PC Board.
Motor Control Hub PC Board.
Check supply power to Motor Control Hub PC Board.
Refer to: Motor Control Hub PC Board Supply Power
Power Supply PC Board.
Check supply power to Motor Control Hub PC Board.
Refer to: Motor Control Hub PC Board Supply Power
