Problem Symptom Probable Cause Check Solution
Tilt function not
operating properly.
No Tilt Up. Active Sensing Technology
TM
activated. For obstruction on the top of column. Remove object from the top of the column.
For obstruction under the foot section. Remove object from under the foot section.
Position of table.
Refer to: Active Sensing Technology
TM
Activate Base Up and Back Up,
then try Tilt Up again.
System malfunction. Error code on Machine Control PC Board. Refer to: Error Codes
Malfunctioning Wired Controls. Wired Controls. Refer to: Wired Controls Malfunctioning
Malfunctioning Wireless Controls. Wireless Controls. Refer to: Wireless Controls Malfunctioning
Seat Smart Sensor switches. Wire connections at J18 on Machine
Control PC Board and at switch.
Secure wire connections.
Refer to: Fuses and Connections
Check two pin inline connection next to
Motor Control Hub PC Board.
Secure wire connections.
Test switches.
Refer to: Smart Sensor Switches
Replace switch(es).
Foot Smart Sensor switches. Wire connections at J18 on Machine
Control PC Board and at switches.
Secure wire connections.
Refer to: Fuses and Connections
Check Green and White wire connections
at four pin inline connection next to
Motor Control Hub PC Board.
Secure wire connections.
Test switches.
Refer to: Smart Sensor Switches
Replace switch(es).
Tilt Up limit switch. Wire connections at J8 on Motor Control Hub
PC Board and at limit switch.
Secure wire connections.
Refer to: Fuses and Connections
Test limit switch.
Refer to: Tilt Actuator / Limit Switches
Replace limit switch.
Tilt Up Overtravel limit switch. Wire connections at J8 on Motor Control Hub
PC Board and at limit switch.
Secure wire connections.
Refer to: Fuses and Connections
Test limit switch.
Refer to: Tilt Actuator / Limit Switches
Replace limit switch.
Troubleshooting Chart - continued
