In the remote location, the Operator Panel snaps to the Operator Panel mounting
cradle, which is first mounted on the wall.
1. Place and level the mounting template [30-S0003], shown in Figure 8, at eye
level in the location where the Operator Panel is to be installed. Tape the
mounting template to the wall.
2. Using an awl or other sharp object, punch through the mounting template to
mark the location for the bolts for the Operator Panel mounting cradle.
3. Drill pilot holes at marked locations. With a drywall knife, cut an opening as
shown on the mounting template.
4. Remove the mounting template from the wall.
5. Using the anchors and screws from the mounting hardware packet, install
the Operator Panel mounting cradle in the position marked.
6. Locate the 25 ft [7.6 m] remote control cable.
7. Run the remote control cable, in compliance with local codes, from the
intended location of the remote Operator Panel to the back of the Control
Unit.
Note: The cable can also be run to an electrical box or opening at the top left
of the wall plate assembly. A sufficient length of cable should be left
available to bring the remote cable out to the bottom front of the Control
Unit.
8. Plug the remote control cable into the bottom of the Power Supply Control
Board 30-08160.
9. Place the top of the front cover on the Control Unit and pop the bottom of
the cover into place, as shown in Figure 36, being careful of the power
switch and cover alignment.
10. Replace the screw on the front cover of the Control Unit.
11. Place the cover plate over the top opening and the small trim cover over the
bottom opening on the front cover of the Control Unit.
12. Locate the Operator Panel in the top portion of the shipping carton.
13. Connect the other end of the remote cable to the right plug (as viewed from
the back) on the bottom of the Operator Panel.
14. Carefully dress the white cable back into the wall.
15. Snap the Operator Panel to the mounting cradle, as shown in Figure 38.
