Midmark Preva - Installing the Remote Exposure Station (30-A2044)

Preva Installation/Service Manual, 00-02-1577, Revision E01
60
Installing the Remote Exposure Station (30-A2044)
The Remote Exposure Station is an option for the Preva that allows the operator
to make the exposure from a fixed location remote from the main unit. As shown
in
Figure 42, a single switch can be used, or two switches can be used in series
or in parallel. Two switches in series will require both switches to be pressed
simultaneously to make an exposure. If two switches are used in parallel, only
one needs to be pressed to make an exposure.
Tools
The following tools are required to install the switch:
• Phillips screwdriver
• Flat-blade screwdriver
• Telephone cable stripper (for dual switch configuration only)
• Wire stripper (for dual switch configuration only)
