Preva Installation/Service Manual, 00-02-1577, Revision E01
71
Showing Current System Configuration
The Preva Dental X-ray System displays the current system configuration.
This display is informational only.
1. From the Main System Configuration menu, Figure 49, select
CONFIGURE UNIT. The Configuration menu shown in Figure 52 will be
displayed.
2. Select SHOW CONFIG. The display will show:
• Current software version
• Cone size
• Diagnostic mode on or off
3. Press any button on the Operator Panel to return to the Configuration
menu.
Figure 52
Configuration Menu
