Preva Installation/Service Manual, 00-02-1577, Revision E01
78
Figure 55
Logic Board
30-08160
Figure 56
Operator Panel
Board 30-08054
TP9 +24V DC
Use TP8 or TP10 for Common Return when
measuring DC voltages.
TP1 +8.1V DC
