Parts 7-27
Power Filter Board Assembly 04-12651
Field Replaceable Parts
Component Description Board Location Part Number
EMI Filter 2200 pF Dual Capacitor F1-F5
5060-15633-00
EMI Filter Ferrite Bead Inductor L1-L5
5556-14181-00
