Setup 1-3
WARNING: AVOID ELECTRICAL SHOCKS
. This video game machine does not utilize
an isolation transformer. Internal, cabinet AC isn’t isolated from the external, AC line.
WARNING: HANDLE FLUORESCENT TUBE AND CRT WITH CARE.
If you drop a
fluorescent tube or CRT and it breaks, it will implode! Shattered glass can fly eight feet
or more from the implosion.
CAUTION: CHECK POWER SELECTOR.
Set the 110/220VAC selector on the power
supply for the correct line voltage. Check the selector setting before switching on the
VGM.
CAUTION: USE PROPER FUSE.
Avoid electrical shock! Replacement fuses must be
of the same type as those they replace. Fuse voltage and current ratings must match
ratings on the original fuse.
CAUTION: ATTACH CONNECTORS PROPERLY.
Be sure that printed circuit board
(PCB) connectors mate properly. If connectors don’t slip on easily, don’t force them. A
reversed connector may damage your VGM and void the warranty. Connector keys only
allow a connector to fit one set of pins on a board.
CAUTION: TAKE CARE WHEN SHIPPING HARD DISKS.
The hard disk drive must be
packed in an anti-static bag. When shipping the drive for repair or replacement, pack it
in an approved container (P/N 08-8068). Never stack or drop hard disk drives.
NOTICE:
This manual is subject to change without notice. Midway reserves the right to make
equipment improvements as engineering progress warrants.
PRODUCT SPECIFICATIONS
Operating Requirements
Location
Domestic
Foreign
Japan
Electrical Power
120VAC @ 60Hz 4.0 Amps
230VAC @ 50Hz 2.0 Amps
100VAC @ 50Hz 4.0 Amps
Temperature
32°F to 100°F
(0°C to 38°C)
Humidity
Not to exceed 95% relative
Cabinet Statistics
Shipping Dimensions
Cabinet
Shipping Dimensions
Seat Pedestal
Shipping Weight
Cabinet
Boxed, 360 lbs. (163 kg.)
Seat pedestal
Width
Depth
Height
32.0" (81.3 cm)
42" (169 cm)
76.0" (193 cm)
Width
Depth
Height
22.0” (55.8 cm)
36.0” (91.4 cm)
51.0” (130 cm)
Boxed, 125 lbs. (56.8 kg.)
Equipment Characteristics
Video Monitor
Medium Resolution RGB
27” (63.5 cm) CRT
Audio System
Digital Stereo Sound
Two 5.5” (14 cm) and
One 6.5” (16.5 cm) Spkr
Currency Acceptors
2 Coin Mechanism, Coin Counter
Dollar Bill Validator Ready
Electronic Coin Acceptor Ready
