Wiring & Circuit Information 4-2
Harness Connector Prefixes
Prefix Connector Location Example
1 Arcade Computer 1P1
2-- --
3
MagicBus
Interface Board
3P1
4 Fluorescent Lamp 4P1
5 Power Supply 5P1
6 Video Monitor 6P1
7 Wheel Driver Board 7P1
8 Coin Door Area 8P1
9 BB12 Audio Board 9P1
10 LED Interconnect Board 10P1
11 Cabinet 11P1
12 Optional Overhead Marquee 12P1
13 Dashboard 13P1
14 Gas Pedal & Brake 14P1
15 Upper Speakers 15P1
16 Seat Speaker 16P1
17 Dash LED Board 17P1
NOTICE:
Look for the connector prefix on wiring diagrams. The prefix shows you
where you’ll find the connector.
