Water connection spring
adapter
Make sure that the spring adapter for
water connection engages correctly
when a basket or injector unit is
inserted in the machine. It must be 4-5
mm higher than the water connection
inlet in the machine.
If it is not, adjust the adapter
accordingly.
^
Loosen lock ring a.
^
Push up adaptor b.
^
Tighten lock ring c.
Height adjustable upper basket
The upper basket can be adjusted
above and below the middle position
by 2 cm.
Different height items can be
processed in this machine depending
on the position the upper basket is set
at and the inserts used.
To adjust the upper basket:
^
Pull out the upper basket until a
resistance is felt; lift from the runners
and remove.
^ Unscrew the roller bearings on both
sides of the basket witha7mm
spanner and reposition as required.
Areas of application
22
