Technical Information
52
Master Chef Ovens
5.27 Self Clean Temperature Sensor (3R30 & 6R30)
Resistance Value Test
Table 5-1: Self Clean Temperature Sensor resistance values
at various temperatures.
5.28 Rotisserie Motors – Removal (1M15, 2M15)
1. Remove the Front Doors (Section 5.2).
2. Remove the oven (Section 5.5).
3. Remove the Back Panel (Section 5.9 and / or 5.10)
4. Refer to Figure 5-20. Remove the Retaining Screws.
5. Unplug the electrical connections to the Motor(s).
6. Remove the component.
Figure 5-20: Rotisserie Motor and Retaining Screws
Temperature
0
F Temperature
0
C
Resistance
(Ohms)
32 O 1000 Ω
68 20 1078 Ω
77 25 1097 Ω
86 30 1117 Ω
122 50 1194 Ω
212 100 1385 Ω
302 150 1573 Ω
392 200 1758 Ω
482 250 1941 Ω
572 300 2120 Ω
