Miele H397B2 - Front Door, Interior Glass Pane - Removal

Technical Information
56
Master Chef Ovens
5.32 Oven Door, Interior Glass Pane - Removal
1. Remove the Front Door (Section 5.2).
2. Remove the Front Door Outer Glass Pane (Section 5.30).
3. Remove the Front Door Middle Glass Pane (Section 5.31).
4. Remove the Spacer Brackets (Item 2).
5. Remove Interior Glass Pane (Item 1).
Figure 5-24: Oven Door, Interior Glass Pane - Removal
Note
To avoid cooking vapors from entering the door assembly – ensure the
seal remains seated when installing the Interior Glass Pane into the Door
Frame Assembly.
1. Interior Glass Pane
2. Spacer Brackets
