Areas of application
39
Adjusting the upper basket
In order to obtain more space for taller items in the lower or upper
basket, the upper basket can be adjusted between two positions that
are approx. 5cm apart.
Pull out the upper basket.
Unscrew the fixing nuts on both sides.
Lift or lower the basket into the desired position.
Tighten the fixing nuts again.
The upper basket must be level in both positions.
If the upper basket is inclined, a water connection is not possible.
Damage caused by the water connection being positioned
incorrectly.
The position of the water connection needs to be adjusted after the
height of the upper basket has been changed.
When changing the height of the upper basket, always adjust the
water connection accordingly before pushing the upper basket
back in.
Turn the upper basket water connection to the upper or lower
position.
The water connection must click audibly into place.
