Use only detergents and
neutralizers specially designed for
use in washers-disinfectors, and
observe the manufacturer's
recommendations for use!
ALWAYS refer to the information
regarding toxicologically harmless
residual amounts.
The washer-disinfector can be fitted
with a maximum of 4 internal
dispensing systems. They are
colour-coded, to match the dispensing
pumps to the corresponding siphon
tubes.
Dispensing system Colour coding
1 blue
2 white
3 red
4 green
Depending on the application(s)
chosen for this washer-disinfector, the
appropriate amounts of detergent and
neutralizer are dispensed through these
systems.
The washer-disinfector comes
standard-equipped with two internal
dispensing systems:
–
Dispensing system DOS 1 (blue) for
use with alkaline products, e. g.
liquid detergents. The dosing rate is
120 ml/min.
–
Dispensing system DOS 3 (red) for
use with acidic products, e. g.
neutralizers. The dosing rate is
105 ml/min.
Up to two additional dispensing
systems can be installed optionally:
Flow rate Product(s)
120 ml/min alkaline
20 ml/min acidic
The appropriate containers with the
processing chemicals are placed into
the upper drawer of the
washer-disinfector.
additional DOS modules (optional):
–
Dispensing system DOS S 20 for
dispensing acidic processing
chemicals, e.g. neutralizers.
The dosing rate is 20 ml/min.
– Dispensing system DOS NA 120 for
dispensing low-foam,
washer-compatible disinfection
agents or an additional detergent.
The dosing rate is 120 ml/min.
The containers for the optional dosing
systems are placed into the lower
drawer of the washer-disinfector.
Always place two containers into the
lower drawer, even if only one
optional dosing system is retrofitted.
This prevents the containers from
tipping when the drawer is opened
or closed.
If a dispensing system is to
dispense different process
chemicals, the change of chemicals
must be carried out by the Miele
Service Department.
Adding liquid detergents and neutralizers
