Miele PWM 300 SmartBiz User Manual

Installation
*INSTALLATION*
55
Water connection
Cold water connection
The washing machine should be con-
nected to the mains water supply in ac-
cordance with current local and national
safety regulations. The German author-
ities do not require it to have a non-re-
turn valve as the washing machine has
been designed to comply with DIN reg-
ulations.
The flow pressure must amount to a
minimum of 100kPa and must not ex-
ceed 1000kPa. If the pressure exceeds
1000kPa, a pressure reducing valve
must be installed.
For the connection, a stopcock with a
¾" screw thread is required. If this type
of stopcock is not available, only a
qualified installer may connect the
washing machine to the mains water
supply.
The connection point is subject to
mains water pressure.
You should therefore open the stop-
cock slowly and check for leaks.
Correct the position of the seal and
screw thread if appropriate.
The washing machine is not suitable
for connection to a hot water supply.
Maintenance
Only use genuine Miele hoses that have
been tested to withstand pressure of at
least 7000kPa should you ever need a
replacement.
A filter is located in the open end of
the inlet hose and another in the in-
take point to protect the water inlet
valve.
Neither filter may be removed.
Hose extension
Longer hoses 2.5 or 4.0m in length are
available from Miele dealers or the
Miele Customer Service Department as
optional extras.

Miele PWM 300 SmartBiz Specifications

General

Door color	Silver
Door hinge	Right
Water fill	Cold
Cord length	2 m
Drum volume	64 L
Control type	Rotary, Touch
Loading type	Front-load
Product color	White
Built-in display	Yes
Inlet hose length	1.55 m
Custom panel-ready	No
Door opening angle	167 °
Illumination color	Yellow
Outlet hose length	1.5 m
Appliance placement	Freestanding
Dispenser tray type	3-way
Current	10 A
Connected load	2400 W
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Energy efficiency scale	A to G
Power consumption (off)	0.4 W
Water consumption per cycle	37 L
Energy consumption washing per cycle	0.76 kWh
Drum capacity	7 kg
Cycle time (max)	199 min
Delay start (max)	24 h
Residual moisture	48 %
Spin-drying class	B
Maximum spin speed	1400 RPM
Noise level (spin)	69 dB
Noise level (wash)	50 dB
Number of washing programs	12
Cycle time (quick washing program)	15 min
Package depth	690 mm
Package width	660 mm
Package height	944 mm
Package weight	95000 g

Weight and Dimensions

Depth	636 mm
Width	596 mm
Height	850 mm
Weight	91000 g
Door diameter	300 mm
Depth with door open	1054 mm
