Miele PWM 300 SmartBiz User Manual

Programmable functions
67
Temperature reduction
At high altitudes, water has a lower
boiling point. Miele recommends ac-
tivating the Temperature reduction set-
ting at altitudes of 2000m or above to
prevent water from boiling.
Options
 = The Temperature reduction set-
ting is switched off (factory
default setting)
 = The Temperature reduction set-
ting is switched on
Maximum rinse level
The water level in the rinses can be
permanently set to the highest value in
the Cottons and Minimum iron pro-
grammes.
This function is important for allergy
sufferers as it achieves excellent wash
results. The water consumption will be
increased.
Options
 = Maximum rinse level is
switched off (factory default
setting)
 = Maximum rinse level is
switched on
Suds cooling
Additional water flows into the drum at
the end of the main wash to cool the
suds down.
Suds cooling takes place when the Cot-
tons programme with a temperature of
70°C or higher is selected.
Suds cooling should be activated:
– To prevent the danger of scalding if
the drain hose is hooked over the
edge of a sink or basin
– Where the drainage pipes do not
comply with DIN1986
Options
 = Suds cooling is switched off
 = Suds cooling is switched on
(factory default setting)

Miele PWM 300 SmartBiz Specifications

General

Door color	Silver
Door hinge	Right
Water fill	Cold
Cord length	2 m
Drum volume	64 L
Control type	Rotary, Touch
Loading type	Front-load
Product color	White
Built-in display	Yes
Inlet hose length	1.55 m
Custom panel-ready	No
Door opening angle	167 °
Illumination color	Yellow
Outlet hose length	1.5 m
Appliance placement	Freestanding
Dispenser tray type	3-way
Current	10 A
Connected load	2400 W
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Energy efficiency scale	A to G
Power consumption (off)	0.4 W
Water consumption per cycle	37 L
Energy consumption washing per cycle	0.76 kWh
Drum capacity	7 kg
Cycle time (max)	199 min
Delay start (max)	24 h
Residual moisture	48 %
Spin-drying class	B
Maximum spin speed	1400 RPM
Noise level (spin)	69 dB
Noise level (wash)	50 dB
Number of washing programs	12
Cycle time (quick washing program)	15 min
Package depth	690 mm
Package width	660 mm
Package height	944 mm
Package weight	95000 g

Weight and Dimensions

Depth	636 mm
Width	596 mm
Height	850 mm
Weight	91000 g
Door diameter	300 mm
Depth with door open	1054 mm
