2. Loading the washing machine
25
Opening the door
 Reach under the door grip and pull
the door open.
Check the drum for foreign objects
before loading it with laundry.
 Unfold the laundry and load loosely
into the drum.
Mixing both large and small items gives
better wash results and also helps to
distribute the load evenly during spin-
ning.
The most efficient use of energy and
water is achieved when a full load is
washed. However, do not overload as
this reduces cleaning efficiency and
causes creasing.
Closing the door
 Make sure that no items are caught
between the door and the seal.
 Shut the door with a gentle swing.

Miele PWM 507 Specifications

General

Drum capacity	7 kg
Delay start (max)	24 h
Spin-drying class	A
Maximum spin speed	1600 RPM
Noise level (spin)	72 dB
Noise level (wash)	- dB
Delayed start timer	Yes
Number of washing programs	-
Current	16 A
AC input voltage	400 V
AC input frequency	50 Hz
Energy efficiency scale	A to G
Water consumption per cycle	37 L
Energy consumption washing per cycle	- kWh
Door hinge	Right
Water fill	Cold, Hot
Drum volume	64 L
Control type	Rotary
Loading type	Front-load
Product color	White
Door opening angle	167 °
Appliance placement	Freestanding
Package weight	104000 g

Weight and Dimensions

Depth	714 mm
Width	605 mm
Height	850 mm
Weight	100000 g
Door diameter	300 mm
