Miele PWM 507 User Manual

Installation
67
Transporting the washing ma-
chine to its installation site
 Danger of injury from incorrect
transport.
If the washing machine tips up there
is a danger of injury to people and
damage to property.
Make sure the washing machine is
stable during transportation.
Transporting the washing machine
with a sack truck
 If transporting the washing machine
with a sack truck, make sure its left or
right side is resting on the truck.
 Risk of damage from incorrect
transport.
The front or back of the washing ma-
chine may be damaged if the ma-
chine is transported with a sack
truck.
Always insert the sack truck under
one of the sides of the washing ma-
chine.
Transporting the washing machine to
its installation site
The protruding lid at the back can be
used to hold the machine when trans-
porting.
 Danger of injury due to unsecure
lid.
The fixings at the back of the lid
could break as a result of external
forces. There is a danger of the lid
being pulled off when carrying the
machine.
Before carrying the machine, check
that the lid is secure where it pro-
trudes at the back of the machine.
 Carry the washing machine by the
front feet and by the lid where it pro-
trudes at the back of the appliance.

Miele PWM 507 Specifications

General

Drum capacity	7 kg
Delay start (max)	24 h
Spin-drying class	A
Maximum spin speed	1600 RPM
Noise level (spin)	72 dB
Noise level (wash)	- dB
Delayed start timer	Yes
Number of washing programs	-
Current	16 A
AC input voltage	400 V
AC input frequency	50 Hz
Energy efficiency scale	A to G
Water consumption per cycle	37 L
Energy consumption washing per cycle	- kWh
Door hinge	Right
Water fill	Cold, Hot
Drum volume	64 L
Control type	Rotary
Loading type	Front-load
Product color	White
Door opening angle	167 °
Appliance placement	Freestanding
Package weight	104000 g

Weight and Dimensions

Depth	714 mm
Width	605 mm
Height	850 mm
Weight	100000 g
Door diameter	300 mm
