Supervisor level
87
Payment system
External hardware is connected via the
Miele XCI box.
If you wish to change the settings after
the commissioning process, please
contact Miele Service.
Settings for payment systems
You would like to connect a payment
system.
– No payment system
The next settings are skipped and ini-
tial commissioning can be com-
pleted.
– Programme operation
The machine is operated using a coin
box. The user purchases a wash pro-
gramme.
– Timed operation
The machine is operated using a coin
box. The user purchases a time-man-
aged programme.
– Timed operation with pulse counter
For payment systems where the us-
age time is increased each time a
coin is inserted.
Feedback signal to pay system
Setting the feedback signal for the
coin box.
– Factory default: Off
– End of programme
The feedback signal is sent at the
end of the programme.
– Release of the start button
The feedback signal is sent when the
start button is released.
– Start and programme end
The feedback signal is sent at the
start and end of the programme.
– Programme running
The feedback signal is sent con-
stantly between the start and end of
the programme.

Miele PWM 507 Specifications

General

Drum capacity	7 kg
Delay start (max)	24 h
Spin-drying class	A
Maximum spin speed	1600 RPM
Noise level (spin)	72 dB
Noise level (wash)	- dB
Delayed start timer	Yes
Number of washing programs	-
Current	16 A
AC input voltage	400 V
AC input frequency	50 Hz
Energy efficiency scale	A to G
Water consumption per cycle	37 L
Energy consumption washing per cycle	- kWh
Door hinge	Right
Water fill	Cold, Hot
Drum volume	64 L
Control type	Rotary
Loading type	Front-load
Product color	White
Door opening angle	167 °
Appliance placement	Freestanding
Package weight	104000 g

Weight and Dimensions

Depth	714 mm
Width	605 mm
Height	850 mm
Weight	100000 g
Door diameter	300 mm
