Installation
66
Installation locations
Side view
1132
850
1100
714
Washer-dryer stack
min. 300
1702
The washing machine can be installed
as a washer-dryer stack together with a
Miele tumble dryer. A WTV stacking kit
(optional accessory) is required for this.
Installation on a plinth
The washing machine can be installed
on a steel plinth (open or closed, avail-
able as an optional Miele accessory) or
on a concrete plinth.
 Injury can occur if the washing
machine has not been adequately
secured.
When installing the machine on a
plinth, there is the danger of the
washing machine falling off the plinth
during spinning.
Secure the washing machine using
the clamps supplied.
Installation notes
This washing machine is not suitable
for building under.
 Risk of damage due to moisture
ingress.
Moisture can damage electrical com-
ponents.
Do not install the machine near or
directly above an open gully or floor
drain.
The washing machine must not be
connected to devices such as timers
which would switch it off automatic-
ally.

Miele PWM 507 Specifications

General

Drum capacity	7 kg
Delay start (max)	24 h
Spin-drying class	A
Maximum spin speed	1600 RPM
Noise level (spin)	72 dB
Noise level (wash)	- dB
Delayed start timer	Yes
Number of washing programs	-
Current	16 A
AC input voltage	400 V
AC input frequency	50 Hz
Energy efficiency scale	A to G
Water consumption per cycle	37 L
Energy consumption washing per cycle	- kWh
Door hinge	Right
Water fill	Cold, Hot
Drum volume	64 L
Control type	Rotary
Loading type	Front-load
Product color	White
Door opening angle	167 °
Appliance placement	Freestanding
Package weight	104000 g

Weight and Dimensions

Depth	714 mm
Width	605 mm
Height	850 mm
Weight	100000 g
Door diameter	300 mm
