Miele PWM 507 User Manual

Programme chart
38
Silks Cold to 30°C Max. load2.5kg
Use for Silks and all hand-washable textiles which do not contain wool
Tip – Follow the instructions on the care label.
– Place tights, bras etc. in a laundry bag.
600rpm Extras: Rinse plus Rinses: 2
Separate rinse Max. load7.0kg
Use for Items which only need to be rinsed and spun
Tip – Observe the spin speed for items which crease easily.
1400rpm Extras: Rinse plus Rinses: 2
Starch Cold to 40°C Max. load3.5kg
Use for Table cloths, serviettes and workwear that need starching
Tip – Laundry that is to be starched should be washed but not treated
with fabric conditioner.
– Observe the spin speed for items which crease easily.
1400rpm Rinses: 1
Clean machine 70°C No load
For cleaning the suds container and the drainage system.
– Add universal detergent to the compartment.
– Use the Clean machineprogramme regularly if you frequently
use disinfection programmes.

Miele PWM 507 Specifications

General

Drum capacity	7 kg
Delay start (max)	24 h
Spin-drying class	A
Maximum spin speed	1600 RPM
Noise level (spin)	72 dB
Noise level (wash)	- dB
Delayed start timer	Yes
Number of washing programs	-
Current	16 A
AC input voltage	400 V
AC input frequency	50 Hz
Energy efficiency scale	A to G
Water consumption per cycle	37 L
Energy consumption washing per cycle	- kWh
Door hinge	Right
Water fill	Cold, Hot
Drum volume	64 L
Control type	Rotary
Loading type	Front-load
Product color	White
Door opening angle	167 °
Appliance placement	Freestanding
Package weight	104000 g

Weight and Dimensions

Depth	714 mm
Width	605 mm
Height	850 mm
Weight	100000 g
Door diameter	300 mm
