Technical Information
W1900 Series Clothes Washers
5.2 Appliance Lid – Removal
1. Refer to Figure 5-2 – Service Access.
2. Remove screws “A” from the edge of the lid.
3. Pull the Lid forward. Lift up the front of the Lid and slide it to the
rear of the appliance.
4. Lift the Lid from the appliance.
5.3 Front Service Panel – Access
Figure 5-2: Service Access
1. Remove the Dispenser Drawer – Refer to Section 5.1.
2. Refer to the figure 5-2. Remove the two screws (Item 1).
3. Open the Washer Door and remove the three 10 mm hex bolts
(Item 2).
4. Open the Front Panel from the left (hinged on the right).
Service Tip:
Before closing the Front Panel, ensure the manual door release is routed
through the slot in the Filter Housing Assembly. Refer to Figure 5-2, Item
3.
36
