Technical Information
W1900 Series Clothes Washers
5.11 Control Electronic – Removal
Service Tip:
Make note / mark the position of the ribbon cables, as they can easily be
installed in reverse (causing the appliance to malfunction).
1. Open the Service Panel – Refer to Section 5.3.
2. Refer to Figure 5-8. Disconnect the plug.
3. Remove the Ribbon Cable (Item 2) from its guide (Item 1) and
disconnect it from the Electronic.
4. Remove the 3 screws (Item 3).
5. Remove the Electronic.
Figure 5-8: Removing Control Electronic
43
