Technical Information
W1900 Series Clothes Washers
5.14 Water Level Switch - Replacement
Note:
This procedure can only be performed on W1903, W1918, W1926 and
W1930 clothes washers.
The W1966 and W1986 washer are equipped with a Level Switch
integrated into the Control Electronic. The Level Switch cannot be
replaced separately.
Figure 5-11: Water Level Switch
1. Open the Front Service Panel – Refer to Section 5.3.
2. Unplug the electrical connection from the Level Switch.
3. Remove the single retaining screw.
4. Lift the Level Switch away from the appliance.
5. Disconnect the Air Hose Connection at the bottom of the switch.
47
