Technical Information
W1900 Series Clothes Washers
5.12 Power Supply Electronic - Removal
1. Open the front Service Panel – Refer to Section 5.3.
2. Refer to Figure 5-9. Use a screwdriver and release the Retainer Clip
(Item 1).
3. Move the Electronic forward to release the retaining lug.
Figure 5-9: Removing the Power electronic
44
