Miller Digital Elite Series User Manual

OM-256476 Page 23
Digital Performance Auto-Darkening Welding Helmet
Item
No.
Part No. Description Qty.
1 250533 Helmet Shell, '64 Custom 1
1 232020 Helmet Shell, Black 1
1 241459 Helmet Shell, Blue Rage 1
1 241461 Helmet Shell, Camouflage 1
1 287366 Helmet Shell, Crusher (Performance) 1
216714 Label, Warning Helmet En/Sp/Fr 1
2 770237 Lens Cover, Inside (4–1/4 x 2 in) (5 Per Pkg.) 1
3 280057 Auto-Darkening Lens Assy. 1
256730 Battery Tray Kit (Left/Right) 1
4 232028 Gasket, Front Lens 1
5 231921 Lens, Front Cover (4–1/2 X 5–1/2 in) (5 Per Pkg.) 1
6 232030 Holder, Front Lens (Flat Black) 1
6 232031 Holder, Front Lens (Gray) 1
6 232032 Holder, Front Lens (Gloss Black) 1
6 232033 Holder, Front Lens (Blue) 1
6 257041 Holder, Front Lens (White) 1
7 284218 Headgear, Grey (Gen 3.5) (Includes). 1
8 *256178 —Adjustment Angle/Stop Hardware Kit 1
9 770249 —Headband, Fabric 1
10 770250 Bag Helmet, Miller 1
♦079975 O-Rings, Replacement (For Item 8) (5 Per Pkg.) 1
♦222003 Adapters, Hard Hat, Band (Not Shown) 1
♦259637 Adapters, Slotted Hard Hat (Not Shown) 1
11 ♦212235 Lens, 0.75 Magnification 1
11 ♦212236 Lens, 1.00 Magnification 1
11 ♦212237 Lens, 1.25 Magnification 1
11 ♦212238 Lens, 1.50 Magnification 1
11 ♦212239 Lens, 1.75 Magnification 1
11 ♦212240 Lens, 2.00 Magnification 1
11 ♦212241 Lens, 2.25 Magnification 1
11 ♦212242 Lens, 2.50 Magnification 1
12 ♦271326 Cushion, Top Headgear 1
* Adjustment Hardware Kit With O-Rings.
♦ Optional

Miller Digital Elite Series Specifications

General

Shade Range	5-13
Product Type	Welding Helmet
Welding Processes	MIG, TIG, Stick
Sensors	4
Power Source	Battery
Battery Type	Lithium
Weight	18 oz (510 g)
