Miller Digital Elite Series User Manual

OM-256476 Page 6
SECTION 3 – SPECIFICATIONS
F
Please register your product at www.MillerWelds.com/Support/Registration
Specification Digital Performance Helmet Digital Elite Helmet
Viewing Field 3.81 x 1.85 in. (97 x 47 mm) 3.81 x 2.62 in. (97 x 60mm)
Operating Modes Three Modes: Weld, Cut, Grind Four Modes: Weld, Cut, Grind,
X-Mode
Reaction Time 0.0000500 sec (1/20,000) 0.0000500 sec (1/20,000)
Available Shades
All Shades Provide Con-
tinuous UV And IR
Protection.
Weld Mode Darkened State:
No. 8–No. 13 Light State: No. 3
Cut Mode Darkened State: No.
5–No. 8 Light State: No. 3
Grind Mode Light State: No. 3
Weld Mode Darkened State:
No. 8–No. 13 Light State: No. 3
Cut Mode Darkened State: No.
5–No. 8 Light State: No. 3
Grind Mode Light State: No. 3
X-Mode Darkened State: No.
8–No. 13 Light State: No. 3
Sensitivity Control
Adjustable For Varying
Ambient Light And Weld-
ing/Cutting Arc. No. 10
Setting Locks Lens In
Dark State.
Weld Mode: No. 0–No. 10
Cut Mode: No. 0–No. 10
Grind Mode: Not Applicable
Weld Mode: No. 0–No. 10
Cut Mode: No. 0–No. 10
Grind Mode: Not Applicable
X-Mode: No. 0–No. 10
Delay Control
Slows Lens Dark-To-Light
State.
Weld Mode: No. 0–No. 10
Cut Mode: No. 0–No. 10
Grind Mode: Not Applicable
Weld Mode: No. 0–No. 10
Cut Mode: No. 0–No. 10
Grind Mode: Not Applicable
X-Mode No. 0–No. 10
Automatic Power Shuts Lens Off 45 Minutes After Last Arc Is Struck. Lens Auto-
matically Turns On When Arc Is Struck.
Low Battery Light Red LED LightsTo Indicate 2-3 Days Remaining Battery Life.
Power Supply Panasonic CR2450 Lithium Batteries (2) (Miller Part No. 217043)
Sensors Independent/Redundant
(Three)
Independent/Redundant (Four)
And Magnetic (In X-Mode)
Operating Temperature 14°F to 131°F / -10°C to +55°C
F
When Stored In Extremely Cold Temperatures, Warm Hel-
met To Ambient Temperature Before Welding.
Storage Temperature -4°F to 158°F / -20°C to +70°C
F
When Stored In Extremely Cold Temperatures, Warm Hel-
met To Ambient Temperature Before Welding.
Total Weight 17 oz. (481.9 g) 18 oz. (510.3 g)
Standards Meets ANSI Z87.1+ And CSA Z94.3 Standards
Warranty Three Years From Date Of Purchase (See Section 11)

Miller Digital Elite Series Specifications

General

Shade Range	5-13
Product Type	Welding Helmet
Welding Processes	MIG, TIG, Stick
Sensors	4
Power Source	Battery
Battery Type	Lithium
Weight	18 oz (510 g)
