Introduction
3
The Q-POD dispenser is detachable from its support. Its dispensing ‘wheel’ delivers water at 3
dierent ows: Low - Medium - High, up 2 L/min.
At the outlet of the dispenser, the nal purication is performed by the application-specic POD-
Pak. The large 7” touchscreen on the HMI oers a wide range of applications for users. It also
has a USB port to easily export data.
Note: High ow reaches above 2L/min when attached to a pressurized loop
When not in active use, the water within the system will recirculate for three minutes every hour.
This is to maintain a clean environment and to avoid contamination. The system should not be
turned o as this will stop the periodic recirculation taking place.
System ow schematics
The system can be fed either by a pressurized loop or a storage tank.
1 Inlet strainer 9 Strainer
2 Inlet valve 10 UV lamp 185mm
3 Feed Conductivity Cell (option) 11 Intermediate resistivity cell
4 Internal Pressure Regulator (option) 12 IPAK Quanta
®
Cartridge
5 Pressure Sensor 13 Product resistivity cell
6 Pump 14 Point Of Dispense (POD)
7 3-way valve 15 Recirculation valve
8 IPAK Meta
®
cartridge
1 2 3 4 5
6
7
8
9 10
11
12
13
14
15
