3.4 Setting the resolution/display for-
mat of the measured value
The resolution of the numerical display can be
adjusted to match the type and size of the ex-
pected indicated value. To do this:
1. Press the MENU key when the standard
display elements are shown. The catalog of
functions and parameters is opened and the
setting “FEATURE (1)” is displayed.
2. Use the DATA and MASTER keys to select
the setting “SETTING (4)”.
3. Press MENU again. The setting “DISPLAY
(4.1)” is displayed.
4. Press MENU again. The setting “FEATURE
(4.1.1)” is displayed.
5. Use the DATA and MASTER keys to select
the setting “RESOL. (4.1.2)”.
6. Press MENU again. The (schematized) num-
ber of places before and after the decimal
point of the numerical display are indicated.
7. Use the DATA and MASTER keys to select
the new display format. The options are:
mm µm inch
ooo.oo ooooo o.oooo
ooo.ooo ooooo.o o.ooooo
ooo.oooo ooooo.oo* o.ooooo5
o.ooooo* o.oooooo*
8. Press START. The selected display format
flashes.
9. Press START again to adopt the flashing dis-
play format. The display then returns to the
catalog of functions and parameters item
“RESOL. (4.1.2)”.
If at this point either the DATA
or MASTER is pressed instead
of START, the display returns to
the display format selection list
(cf. point 7). The display format
can be changed again.
10. If no further settings are to be made in the
catalog of functions and parameters, press
the START key. The standard display ele-
ments appear.
If further settings are necessary, navigate
to the appropriate point of the catalog of
functions and parameters using the ESC,
MASTER, DATA and MENU keys and carry
out the settings as required.
* This format is only available for the Millimar C 1216/C 1240.
