P-4 enter “3”, span (inside diameter of tank)
P-5 enter “.5”, near blanking distance, 3.5 m - 3.0 m = 0.5 m
P-7 enter “1”, display max. 1 digit after decimal
P-34 enter option “7”, tank shape for volumetric conversion
P-35 enter “.75”, tank dimension A
P-36 enter “5”, tank dimension L
P-37 enter “.5”, convert (x 0.5)
automatically show the levels in %. As 100% full = 40.6
cubic meters, a conversion factor of .406 must be entered.
actual volume = conversion factor
percentage
P-68 enter “10”, fill damping 10 m/min
50 cu. m = 143 min total fill time
0.35 m/min.
3 m = 0.021 m/min average fill rate
143 min.
However, because of the tank’s shape, the top and bottom levels will fill
faster than the middle section. Therefore the actual P-68 value should be
greater than the average value. Typically, the factory set damping of “10”
can be used.
P-69 enter “10”, empty damping - same as fill damping rate
P-74 enter option “1”, fail-safe high
P-75 enter “0.5”, fail-safe timer, 30 sec.
press:
to re-enter run mode.
RUN
CAL
PL-399 6 – 18
