P-36 tank dimension L
horizontal length of tank shape 7 excluding parabolic ends (not required
for other tank shapes).
enter “dimension L”, in units selected per P-1 (F=0.000)
P-37 convert display
parameter value is the factor by which the measurement is to be
multiplied by before being displayed. Range is 0.001 to 9999.
enter desired factor (F=1)
P-38 display offset
this value is added to material, space, volume or ullage measurement
before being displayed (P-39, P-76 or programmer key “*”). The mA
output and alarms are not affected by the offset. The display offset is
entered in the units programmed, subject to P-1, P-34 and P-37.
enter offset required (F=0.000)
P-39 display reading options
in the run mode, programmer keys can be pressed to view alternate readings.
Refer to Section IV, Programmer Keypad. The display will return to the
reading option selected (except option 0) after momentarily displaying the
alternate reading.
enter 0 = hold last alternate reading selected (F)
1 = high total: 4 highest digits of the 8 digit
totalizer (pumped volume and OCM only)
= point 1: DLD level / transducer #1
2 = low total: 4 lowest digits of the 8 digit totalizer
(pumped volume and OCM only)
= point 2: DLD level / transducer #2
3 = head (OCM only)
4 = flowrate (OCM only)
5 = reading: level, space, differential,
volume or ullage
1
3
4
*
2
PL-399 7 – 7
