enter 1 = one short pulse only
2 = one long pulse only
3 = two long pulses and one short pulse
4 = one short pulse if target is within 1 m, or (F)
one short pulse and two long pulses if target is beyond 1 m
Parameters P-89 through P-98 for testing.
P-89 software revision number (V)
P-90 memory test (V)
press display will show:
’PASS’ = memory test passed
’1’ = RAM failure
’2’ = EPROM failure
’3’ = EEPROM failure
P-91 LCD, LED and relay test (V)
Note: as this test will cause the relays to change state be sure to
lock out all applicable alarms, pumps and machinery
before pressing “enter”
press
- all LCD segments should flash
- all relays should turn on and off sequentially
- all LED’s should flash sequentially
- press any key to stop
P-92 mA output test
HydroRanger I will output to terminal board, TB1, the displayed mA value
(also by pressing ). Range is approximately 0 to 20.
Upon entering the CAL mode, the prior mA out value will be displayed.
A new test value may be entered or the mA value from pressing can
be viewed. Upon returning to the RUN mode, the parameter value will
assume the actual mA output level. (F=0.000)
enter desired mA value
P-93 temperature sensor ADC counts (V)
P-94 transmitter test (V)
ENTER
5
MEAS
ENTER
PL-399 7 – 20
