Parameter Description
P051 Max Volume
For Readings in volumetric units (rather than percent), enter the vessel
volume between Empty (P006) and Span (P007).
The units of measurement for this reading are non-dimensional. The volume
is calculated from the empty position to the maximum position and is scaled
according to the Tank Shape (P050) value. This enables the use of any
volume units required.
Example
If max. volume = 3650 m
3
, enter 3650.
If max. volume = 267500 gallons, enter 2675 (100's of gallons).
enter the volume of the tank at full (Factory = 1)
Notes:
• Maximum volume entered not to exceed 30,000.
• OCM calculation is an optional feature. MiniRangers with the OCM
feature have this icon on the front: .
P052 Tank Dimension ‘A’
This is dimension ‘A’ as used in P050 Tank Shape.
Enter the height of the tank bottom if P050 = 2,3,4, or 5, or the length of one
end section of the tank if P050 = 7.
enter the dimension in units (P005)
P053 Tank Dimension ‘L’
This is dimension ‘L’ as used in P050 Tank Shape.
Enter the tank length (excluding both end sections) if P050 = 7.
enter the dimension in units (P005)
P062 Offset Reading
Adds the specified value to the level reading, usually to reference the
reading to sea level or another datum level.
The operation of the device is not affected by the Offset Reading. This value
is used for display purposes only. All control measurements are still
referenced to Empty.
The Offset Reading is ignored when open channel monitoring (OCM, P600 =
1) is used.
