Page 66 MiniRanger Plus 7ML19981CJ01
Parameter Description
Status A
1 character, $0 to $F (convert to binary, e.g. temp, echo, and cable OK, not
priority)
MSB LSB
# # # #
0 = reserved
1 = loss of echo (f.s. expired)
1 = transducer cable fault
0 = reserved
Status B
1 character, $0 to $F (convert to binary, e.g. scan point is in high alarm)
MSB LSB
# # # #
1 = low low alarm
1 = low alarm
1 = high alarm
1 = high high alarm
Status C
1 character, $0 to $F (convert to binary, e.g. scan point is not in rate or band
alarm)
MSB LSB
# # # #
0 = reserved
0 = reserved
0 = reserved
0 = reserved
Field Name Definition
Temp
2 characters, $32 to $FA
(convert to decimal and subtract 100, e.g. temperature
= 20 °C)
Percent
5 characters, 00.00 to 9999.
(e.g. current level = 85.00% of span, EEEE. = field
overflow)
End Of Message CR ($0D)
