Milton Roy mRoy XT - Xt Assembly, Liquid End and Base Parts

31
6.3 XT ASSEMBLY, LIQUID END AND BASE PARTS
FIGURE
NUMBER
ITEM
NUMBER
DESCRIPTION PART
NUMBER
QTY REFERENCE
CODE
7, 8 10 Oil Reservoir Cap 20183 1
20 O-Ring, Parker 2-216 BUNA N 4080095071 1
30 O-Ring, 2-022, Nitrile, 90 Duro 40336 2
40 Cap, Seal 21163 1
50 Cap Plate %, Aluminum 2530015062 1
60 Screw, Soc Set, #6-32NC X 1/4 4050039035 1
70 Knob, Locking 21162 1
80 Rod, Control 21161 1
90 Clip, 1/4in., External E-Ring 4040124096 1
100 Knob, Control, Stroke Adj. 20926 1
110 Ring, Calibration, PVC 2530024071 1
120 Ring, Back Up, 8-013, Nitrile 4080126101 1
130 O-Ring, 2-013, Nitrile, 90 Duro 40312 1
140 Plunger, 9/16in. 20342 1
150 Pin, Wrist, Steel 2110030006 1
160 Connecting Rod, Aluminum 2140025062 1
170 Housing, 9/16in. Bore 21170 1
180 Single Ball Check Valve Assy, Discharge CV202265 1
180 Double Ball Check Valve Assy, Dis-
charge
21342 1
190 Plug, Bleeder BV202139 1
195 O-Ring, 2-042, Nitrile, 70 Duro 40673 1
200 Diaphragm, Gyl. 2.84in. Dia. 20407 1
210 Contour Plate 22039 2
215 Pin, Spring, 3/32in. X 3/8in., 420SS 40315 2
220 Screw, Soc Head, 7/16in.-14in. X 1-3/4
in., STL
4050030154 8
230 Faceplate, Diaphragm Head 20936 1
235 Bushing, Reducer, 1/2 - 1/4, NPT 40732 1
240 Single Ball Check Valve Assy, Suction CV202270 1
240 Double Ball Check Valve Assy, Suction 2210264002 1
242 Screw, Hex Head, 5/16in.-18in. X 1-1/2
in., GR5
4050017149 3
244 Washer, Spring Lock, 5/16in. Z Pl 4040040028 3
- Items Not Shown
