6.7 PARTS LIST FOR MROY XW RUPTURE DETECTION
Model:
Liquid End: Material: Reference Code:
XW -- 316SS -- C5 Rupture Detection with Gauge
XW -- 316SS -- SN Rupture Detection with Gauge & NEMA 4 Switch
XW -- 316SS -- S7 Rupture Detection with Gauge & NEMA 7 Switch
XW -- 316SS -- NN None (Standard)
FIGURE
NUMBER
ITEM
NUMBER
DESCRIPTION PART
NUMBER
QTY REFERENCE
CODE
16 242 Screw, HEX HD, 3/8-16 X 2 ULTRA GR5 4050018169 3 C5, SN, S7
244 Washer, Spring Lock, 3/8 18.8SS 4040041022 3 C5, SN, S7
246 Nut, Hex, 3/8-16NC, 18.8SS 4050066012 3 C5, SN, S7
248 Base 21485 1 C5, SN, S7
281 Pin, Spring, 1/16” X 3/8” STL 4010001041 3 C5, SN, S7
285 O-Ring, 2-044 Viton, 70 Duro 4080109415 1 NN
286 Ring, Spacer, 316SS 21474 1 C5, SN, S7
287 Intermediate Ring - A -XW 21472 2 C5, SN, S7
288 Intermediate Ring - B -XW 21473 2 C5, SN, S7
290 Diaphragm, Teflon, 3.390” Dia. 2980015075 1 NN
291 Diaphragm, Gylon, 0.03 THK 41051 2 C5, SN, S7
295 O-Ring, 2-044 Viton, 70 Duro 4080109415 1 C5, SN, S7
330 Diaphragm, Head, 316SS 21484 1 C5, SN, S7
334 Tube, Conn, 1/8” NPT, 316SS 40061 1 C5, SN, S7
350 SHCS, 1/2” -13 X 2.25” Long 40337 8 NN, C5, SN,
S7
380 Switch Bracket 2040206006 1 C5, SN, S7
390 Screw, HEX HD, 5/16-18 X 1/2 STL 4050017071 2 C5, SN, S7
400 Washer, Spring Lock, 5/16 316SS 40409 2 C5, SN, S7
457 Mineral Oil 4070317020 1oz C5, SN, S7
1150 Tube, Check Valve, 1/8”, 1/3 PSI, 316SS 40065 1 C5, SN, S7
1160 Gage, Pressure, 0-5000 PSI 40405 1 C5, SN, S7
1170 Adapter, Reducer, 1/4F X 1/8M NPT
316SS
40067 1 C5, SN, S7
1190 Tee, 1/8” NPT Female, 316SS 40062 1 SN, S7
1191 Tee, 1/8” NPT Female, 316SS 40062 1 C5, SN, S7
1200 Connector, Tube, 1/8” Tubex, 1/8” NPT
316SS
40061 2 C5, SN, S7
1201 Connector, Tube, 1/8” Tubex, 1/8” NPT
316SS
40061 2 SN, S7
1210 Valve, Bleed, 1/8” NPT, 316SS 40063 1 C5, SN, S7
- Items Not Shown
