Milton Roy mRoy XT - Page 59

53
FIGURE
NUMBER
ITEM
NUMBER
DESCRIPTION PART
NUMBER
QTY REFERENCE
CODE
16 1220 Screw, Pan Head, #4-40X1/2” 4050263050 3 C5, SN, S7
1230 Washer, Spring Lock, #4 18-8SS 4040095023 3 C5, SN, S7
1240 Nut, Hex, #4-40NC, 18-8SS 4050182012 3 C5, SN, S7
1250 Switch, NEMA 4 Pressure, 5-30 PSI 4060388001 1 SN
1250 Switch, NEMA 7 Pressure, 5-30 PSI 4060389001 1 S7
1260 Nipple, Reducing Hex, 12”X1/8” NPT
316SS
40064 1 SN, S7
1270 Screw, HEX HD, 1/4”-20 X 3/4 18-8SS 4050016095 2 SN, S7
1280 Washer, Spring Lock, 1/4” 18-8SS 4040039022 2 SN, S7
1290 Nut, Hex, #1/4-20NC, 18-8SS 4050064012 2 SN, S7
1320 Tube, 1/8” ODX 0.028Wall, 316SS 50108 12in. SN
1320 Tube, 1/8” ODX 0.035 Wall, 316SS 4020502993 20in. SN, S7
1320 Tube, Gauge to Switch, NEMA 7 2490138016 1 S7
- Items Not Shown
