Milton Roy mRoy XT - Parts List for Xt Pump with Rupture Detection

41
6.5 PARTS LIST FOR XT PUMP WITH RUPTURE DETECTION
FIGURE
NUMBER
ITEM
NUMBER
DESCRIPTION PART
NUMBER
QTY REFERENCE
CODE
12 195 O-Ring, 2-042, Nitrile, 70 Duro 40673 1
230 Faceplate 20936 1
248 Base, Leak Detection 2010626000 1
281 Pin, Spring, 1/16in. X 3/8 4010001041 3
285 O-Ring, 2-041, BUNA-N 40828 1
286 Ring, Spacer, 316 SS 21238 1
287 Ring, Intermediate, A 21029 2
288 Ring, Intermediate, B 21031 2
290 Diaphragm, GYLON, 0.030 Thick 40741 2
295 O-Ring, 2-042, NITRILE 40673 1
380 Leak Detection MTG Bracket 21682 1
390 Screw, Hex Head, 5/16in. - 18 X 1/2in. 4050017071 2
400 Lock Washer, Spring, 5/16in 40409 2
457 Mineral Oil 4070317020 1OZ
1150 Check Valve 1/8 in. Tube 40065 1
1160 Gauge, Press, 0-5000 PSI 40405 1
1170 Adapter, Reducer, 1/4in X 1/8in. NPT,
316SS
40067 1
1190 Tee, 1/8in. NPT Female, 316SS 40062 1 SN, S7
1191 Tee, 1/8in. NPT Female, 316SS 40062 1
1200 Connector, Tube, 1/8in. Tubex 1/8in.
NPT 316SS
40061 2 SN, S7
1201 Connector, Tube, 1/8in. Tubex 1/8in.
NPT 316SS
40061 2
1210 Valve, Bleed, 1/8in. NPT 316SS 40063 1
1220 Screw, Pan Head, #4-40 X 1/2in. 4050263050 3
1230 Lock Washer, Spring, #4 18-8SS 4040095023 3
1240 Nut, Hex, #4-40NC, 18.8SS 4050182012 3
- Items Not Shown
Model:
Liquid End: Material: Reference Code:
XT -- 316SS --- C5 Rupture Detection with Gauge
XT -- 316SS --- SN Rupture Detection with Gauge & NEMA 4 Switch
XT -- 316SS --- S7 Rupture Detection with Gauge & NEMA 7 Switch
