Milton Roy mRoy XT - Page 39

33
FIGURE
NUMBER
ITEM
NUMBER
DESCRIPTION PART
NUMBER
QTY REFERENCE
CODE
7, 8 Threaded, 150#, 1/2 RF Flange
- NIPTHRDSCH80, 1/4x3, 316 SS, 4020050223 2
- Flange, 150#, THD, 1/2 X 1/4, 316SS 4020313023 2
- Elbow, Street, 1/4, 6000#, 316 SS, Dis-
charge
41008 1
- 90 Degree Elbow, 2000#, THRD 1/4,
316SS, Suction
4020018023 1
Threaded, 300#, 1/2 RF Flange
- NIPTHRDSCH80, 1/4x3, 316 SS, 4020050223 2
- Flange, 300#, THD, 1/2 X 1/4, 316SS 4020361023 2
- Elbow, Street, 1/4, 6000#, 316 SS, Dis-
charge
41008 1
- 90 Degree Elbow, 2000#, THRD 1/4,
316SS, Suction
4020018023 1
Threaded, 600#, 1/2 RF Flange
- NIPTHRDSCH80, 1/4x3, 316 SS, 4020050223 2
- Flange, 600#, THD, 1/2 X 1/4, 316SS 4020629023 2
- Elbow, Street, 1/4, 6000#, 316 SS, Dis-
charge
41008 1
- 90 Degree Elbow, 2000#, THRD 1/4,
316SS, Suction
4020018023 1
- Items Not Shown
