FIGURE

NUMBER

ITEM

NUMBER

DESCRIPTION PART

NUMBER

QTY REFERENCE

CODE

9, 10, 11 410 Shaft, Worm 20863 1 FR, F4, FS,

420 Worm, 9.5:1 2520086106 1

420 Worm, 15:1 2520019100 1

420 Worm, 24:1 2520090106 1

420 Worm, 48:1 2520051006 1

420 Worm, 77:1 2520126006 1

440 Coupling, 1/2in. x 5/8 in. 4100127040 1 FR

440 Coupling, 7/8IN. X 1/2IN., LOVEJOY 4100064120 1 F4

440 Coupling, 1/2IN. X 14MM, LOVEJOY 40202 1 FS

440 Coupling, L-100, LOVEJOY 40244 1 MD

445 Adapter Plate, Motor 60199 1 MD

450 Adapter, Motor 2720090001 1 FR, F4, MD

450 Adapter, Motor 2720146001 1 FS

460 Screw, Socket Head, #8-32NC x 3/4in.

STL

4050132031 4 FR, F4, FS,

470 Washer, Finger Spring, 0.563in. 4030121006 2 FR, F4, FS,

475 Pin, Spring, 1/8 x 1/2 4010003031 3 SS

480 Washer, Flat 2190030006 1 FR, F4, FS,

485 Gasket, Motor 2250115099 1 SR, FR, F4,

485 Gasket, Motor 2250121099 1 SS, FS

490 Bearing, Ball 4090094020 1 FR, F4, FS,

495 Spring 4030166011 1 SR

495 Spring 60059 1 SS

- Items Not Shown
