Rendering the set values on the personal computer effective
[MODE SET] > [CMD SW]
The set values (commands) that are rendered effective are specified either those set on the operation
panel or those set on the CAD.
Set values
VALID: If items that are set on the operation panel of this device can also be set on the
CAD, the latest command specified is given priority. If the device receives data
set on the CAD after the data have been set on the operation panel, the data
received will be given priority.
INVALID: Commands that are set on the operation panel of the device are given priority
while ignoring commands set on the CAD.
1 Press the
PAGE
+
key several times
until the LCD indicates page 3 of the
LOCAL MENU.
2 Select the [MODE SET].
3 Press the
PAGE
+
key several times
until the LCD indicates page 3 of the
[MODE SET].
4 Set the [CMD SW] to one of the fol-
lowing.
VALID, INVALID
5 Enter the input values.
Press the
END
key to enter the input
values.
If you do not enter the input data, press
the
END
key.
[ LOCAL ] 1 / 4
TOOL SELECT ———>
CONDITION ———>
TEST CUT ———>
[ LOCAL ] 3 / 4
INTERFACE ———>
MODE SET ———>
SELF TEST ———>
< MODE SET > 1 / 5
Z STROKE 7mm >
MULTI-PASS ——— >
VACUUM AutoOFF>
< MODE SET > 3 / 5
ROTATE +90° >
COMMAND ——— >
CMD SW INVALID >
< MODE SET > 3 / 5
ROTATE +90° >
COMMAND ——— >
CMD SW VALID >
END
[ LOCAL ] 3 / 4
INTERFACE ———>
MODE SET ———>
SELF TEST ———>
F3
+
F2
+
PAGE
+
PAGE
+
